• Current Rating：50mA
• Voltage Rating：28VDC
• Contact Resistance：100m Max (intial DC5V 1mA)
• Insulation Resistance：500M Min
• Operating Force：400±150gf
• Total Travel：1.0±0.35mm
• Opearating Force：500,000 Cycles Min
• Circuit：SPST 1P1T with LED
• Dielectric Withstanding Voltage：250VAC for 1 minute
• Soldear Specifications：260℃ for 3 seconds
• Function：Momentary
• Openrating Temperature：-40℃ ~ + 95℃
|
    |
| Part Number | Contact Resistance | Insulation Resistance | Operating Force | Total Travel | Circuit | Current Rating | Voltage Rating | Dielectric Withstanding Voltage | Openrating Temperature | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|---|
| R2990-N-Y-V-TR | 100m Max (intial DC5V 1mA) | 500M Min | 400±150gf | 1.0±0.35mm | SPST 1P1T with LED | 50mA | 28VDC | 250VAC for 1 minute | -40℃ ~ + 95℃ | 暫無(wú) |
